Product Name : MICROPHONE CARTRIDGES
Product Model : CDM-151

Characteristics:

• The patented design; the uni-directional sensitivity caused by the outer magnet; is first use in the structure to enhance the robustness of the unit.
• Even when the unit is hit by the external impact; it will not affect the sound quality.
Sound is soft.
• Suitable for use in KTV; CB Microphone or music instrument performance

Specificatios

TYPE                                             Dynamic Microphone CartridgeDIRECTIONAL                              Uni-DirectionalSENSITIVITY                                -74 dB ± 3dB (at 1000Hz)FREQUENCY RESPONSE          See BelowOUTPUT IMPEDANCE                500 ΩWEIGHT                                       32 g
